|Inlet Water Pressure:||0.1-0.45Mpa||1st Stage:||PP Filter Cartridge|
|2nd Stage:||UDF Filter Cartridge||3rd Stage:||CTO Filter Cartridge|
|• Tank Size:||3.2G Or 4G||• Flush Type:||Auto Flush Or Manual Flush|
ro water purifier filters,
ro system water filter
Product Introduction --------------------------------------------------
1st Stage --- PP sediment filter, 5 micron, it can remove the particles, sands, and other impurities.
2nd Stage --- Granular activated carbon filter, GAC/UDF, it can adsorb the chlorine in the tap water, also remove the odor, smell, and bad taste.
3rd Stage --- CTO cartridge, it can further adsorb more tiny organic substance, odor and bad taste.
4th Stage --- UF membrane, 0.01 micron, it can remove the bacterium and substance.
5th Stage --- Energy filter cartrige, alkaline balls, king of chlorine, mineral stones, it contains the trace elements which good for human body, it has strong adsorbtion ability.
6th Stage --- T33 Post carbon filter, it can improve the water taste.
Product Parameter -----------------------------------------------------
|Inlet water pressure||0.1-0.45Mpa|
|Flow rate||3.8L/m 2L/min|
|Applicable water quality||Municipal tap water|
Ro water purifier osmosis
|Stage||Description||Component Item No.||Replace time||Function|
|1st||5um pp Spun Fiber||PP-10”||2-3months||Remove the particles,dust,mud etc.|
|2nd||Granular Carbon Filter||GAC-10”(UDF-10)||4-6month||Remove the chlorine,organics,odor,smell turbidity etc.|
|3rd||Block Carbon Filter||CTO-10”||4-6months||Remove the chlorine,odor,smell and suspending particles.|
|4th||RO membrane||CSM or FCS or FILMTEC||1-2yesrs||Remove the bacteria,heavy metal,salt,bad mineral substance and other dissolved matter and chemical drug in the running water|
|5th||Post inline Carbon Filter||T-33||1year||Adjust the taste.|
|6th||UFmembrane||UF-10||1-2years||Concentrates particles,collolds and separates them from raw water.|
|7 TH||Uv light||6W||1-2years||Kill bacteria viruses,mocro-organisms in water|
When the source water enters the system it goes through stages one, two, and three, collectively known as the pre-filters. The job of the pre-filters is to remove large contaminants and protect the RO membrane from chemicals like chlorine and chloramines.
After the water has passed through the pre-filters, it is forced through the NSF certified reverse osmosis (RO) membrane, the same technology used to produce bottled water. This semi-permeable membrane features tiny 0.0001 micron sized holes, equivalent to just 0.000000004 of an inch. This allows it to effectively remove a long list of water contaminants only possible with reverse osmosis.
The fifth and final stage of filtration utilizes a finer GAC filter known as the post carbon filter. This provides a final polishing before the purified water is delivered to the faucet.
The end result is bottled quality water. In addition to the cost savings and health benefits, widespread use of in home filtration systems would reduce the impact of plastic bottles on the environment tremendously. With all of the benefits, it only makes sense to go RO!
